Klüberfood NH1 94-402, 400g, Kluber Lubrication 0960970591
Available from factory - Estimated to ship in: 21 days.
Klüberfood NH1 94-402, 400g, Kluber Lubrication PN: 0960970591
Synthetic special lubricating grease for the food processing and pharmaceutical industries
The Benefits
- Increased component availability and extended maintenance intervals.
owing to its good load-carrying capacity
due to good corrosion protection
- Reduces friction and wear, e.g. in rolling bearings, owing to its good wear protection properties and good flow characteristics.
- ISO 21469 certified- supports the compliance with hygienic requirements in your production plant.
The Solution
Klüberfood NH1 94-402 is a special lubricating grease composed of a highly refined base oil and a calcium complex thickener.
The use of Klüberfood NH1 94-402, an NSF H1-registered lubricant, can contribute to a safe product regime when used in accordance with food manufacturing regulations.
Klüberfood NH1 94-402 is NSF H1 registered and therefore comply with FDA 21 CFR § 178.3570. The lubricant was developed for incidental contact with products and packaging materials in the food-processing, cosmetics, pharmaceutical or animal feed industries. The use of Klüberfood NH1 94-402 can contribute to increase reliability of your production processes. We nevertheless recommend conducting an additional risk analysis, e.g. HACCP.
Application
Klüberfood NH1 94-402 is used for the lubrication of rolling bearings of machines and installations used in the food-processing industry, e.g. in the manufacture of grain, meal and pellet animal feeds.
Application Notes
Klüberfood NH1 94-402 is applied by standard commercial grease application equipment, e.g. spatula, grease gun. Before applying Klüberfood NH1 94-402, all lubrication points should be thoroughly cleaned to ensure maximum hygiene conditions exist, mandatory for food-safe H1 lubrication.
Product Data
| Article number | 096097 |
| Color Space | Beige |
| Texture | Homogeneous |
| Lower service temperature | -30 °C |
| Upper service temperature | 160 °C |
| NSF H1 Registration Number | 139051 |
| Texture | fibrous, homogeneous |
| Density at 20 °C | approx. 0.97 g/cm³ |
| Worked penetration, DIN ISO 2137, 25 °C, lower limit value | 280 x 0.1 mm |
| Worked penetration, DIN ISO 2137, 25 °C, upper limit value | 310 x 0.1 mm |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °C | approx. 400 mm²/s |
| Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °C | approx. 40 mm²/s |
| SKF-EMCOR, DIN 51802, Klüber method: distilled water, 168 h | <= 1 corrosion degree |
| Oil separation, ASTM D6184, based on standard, 30 h, 100°C | <= 1 400 mbar |
| Drop point, DIN ISO 2176, IP 396 | ≤4%by weight |
| Flow pressure, DIN 51805-2, -30°C | approx. 1400 mbar |
| Dropping point, DIN ISO 2176 / IP 396 | ≥250°C |
| Four-ball tester, welding load, DIN 51350-4 | approx. 3000 N |
| Speed factor (n x dm) | approx. 300000 mm/min |
| Minimum shelf life from the date of manufacture - in a dry, frost-free place and in the unopened original container, approx. | 24 months |
