Kluberplex BEM 41-132 High-temperature and long-term grease 370g, Kluber Lubrication, 0202560591

Kluberplex BEM 41-132 High-temperature and long-term grease 370g, Kluber Lubrication 0202560591

$34.98
Sign In for your price

In Stock 30. Additional units to ship in: 21 days.

Kluberplex BEM 41-132 High-temperature and long-term grease 400g, Kluber Lubrication PN: 0202560591


Klüberplex BEM 41-132 is based on synthetic hydrocarbon oil, mineral oil and a special lithium soap. Special additives ensure optimum oxidation resistance as well as protection against wear and corrosion.


Benefits for your application

  1. Longer service life due to special wear additives for roller bearings
  2. Less maintenance
  3. Versatile grease due to wide operating temperature range and optimised oil release


Application

  1. Klüberplex BEM 41-132 can be used for long-term or lifetime lubrication of rolling bearings at operating temperatures between 70 and 110 °C.
  2. For rolling bearings with a high degree of sliding friction, e.g. tapered roller bearings, cylinder roller bearings, spherical roller bearings
  3. For-life lubricated deep groove ball bearings and rolling bearings e.g. in paper-making machines (dry section), textile machines (dry section), electric motors, hot air blowers drying ovens, air separators in the base materials industry, generators in wind power plants
  4. Rolling bearings in vehicle components
  5. Clutch bearings
  6. Generator bearings
  7. Water pump bearings
  8. Fluid fan bearings


Technical specifications

Lubricating greases -K, DIN 51825 in connection with DIN 51502KPHC2N-30L
Chemical composition, thickenerspecial lithium soap
Chemical composition, type of oilsynthetic hydrocarbon oil
Chemical composition, type of oilmineral oil
Lower service temperature-40 °C / -40 °F
Upper service temperature150 °C / 302 °F
Color spaceyellow
Density at 20 °Capprox. 0.90 g/cm³
Worked penetration, DIN ISO 2137, 25 °C, lower limit value265 x 0.1 mm
Worked penetration, DIN ISO 2137, 25 °C, upper limit value295 x 0.1 mm
Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 40 °Capprox. 120 mm²/s
Kinematic viscosity of the base oil, DIN 51562 pt. 01/ASTM D-445/ASTM D 7042, 100 °Capprox. 14 mm²/s
Corrosion inhibiting properties of lubricating greases, DIN 51802, (SKF-EMCOR), test duration: 1 week, distilled water<= 1 corrosion degree
Drop point, DIN ISO 2176, IP 396>= 250 °C
Speed factor (n x dm)approx. 1 000 000 mm/min
Oil separation, DIN 51817 N, after 7 d/40 °C<= 4 % by weight
Testing of lubricating greases on FAG FE9 rolling bearing tester, DIN 51821 pt. 02, speed: 6000 min-1, axial load: 1500 N, temperature: 150 °C, service life F50:>= 100 h
Low-temperature torque, IP 186, -40 °C, start<= 1 000 mNm
Low-temperature torque, IP 186, -40 °C, running<= 200 mNm
Minimum shelf life from the date of manufacture - in a dry, frost-free place and in the unopened original container, approx.36 months
